The AiRanger™ is an industry-leading fixed-wing unmanned aircraft.



Boasting an 18.2-foot wingspan, reliable propulsion system, and payload capability (up to 75 pounds), the AiRanger has an endurance of over 15 hours (with payload).



Powered by fuel-injected gasoline engine, the AiRanger is designed for commercialized airborne applications in austere environments at large scale. Generating <5.5 lbs CO2 per hour, the aircraft can carry multiple sensors simultaneously, including remote sensing, surveillance, particulate sensors and small cell sites for emergency communications.

Modular in design, the AiRanger is designed to be configured for a wide variety of applications utilizing cutting edge avionics aimed at safe and efficient large-scale operations in civil airspace.

  • Designed to achieve equivalent levels of safety through technology & procedural methodology

  • Multi-layered Detect-and-Avoid (DAA) Systems

  • Multiple/redundant communication options

  • Compatible with multiple payloads

  • Advanced flight planning and operations software

  • For price and delivery please contact AiRanger@americanaerospace.com

​​

Industrial Grade Type Certified Flight Systems - Coming Soon​

AiRanger™
Medium Altitude, Long-Endurance
Unmanned Aircraft System (UAS)

Specifications

Length:

Endurance:

Range:

Service Ceiling:

Speed (dash/typ. cruise/min):

Engine Power:

Maximum Takeoff Weight:

Empty Weight:

Payload Bays:

Max. Payload Weight:



Onboard Power:

Launch/Recovery:

Communications:

Wing Span:

10 ft

15+ hours (configuration dependent)

750 miles

15,000 ft

100 kts/ 50-75 kts / 50 kts

8.2 hp

220 lbs

145 lbs

Fuselage and Wing Hard Points



75 lbs (Payload + Fuel)

1,150+ watts (600 watts available for payloads)

Lightweight catapult / belly skid landing

Line of sight (LOS), Beyond-Line of sight (BLOS), Global BVLOS (SATCOM + LTE)

18.6 ft


AiRanger Use Cases

Linear Infrastructure Patrol
Ports & Harbors
Upstream Oil & Gas Fields
offshore-construction-platform-for-production-oil-and-gas-oil-and-gas-picture-id1317214769
Offshore Wind
Disaster Response
Downloads
AiRanger™ Specification Sheet
AiRanger UAS Mission Packages
AiRanger™ selected for NASA SIO Demonstration

The AiRanger™ is available as a service through AATI's Airborne Systems Group (ASG), available for purchase, and also available to be configured with AATI's Instimaps payload.
